28. Remove the transmission crossmember bolts (1).
29. Remove the transmission crossmember (4).
Fig. 29: Left Transmission Mount Bolts
Courtesy of CHRYSLER LLC
30. Lower the engine and transmission to gain access to the left transmission mount bracket bolts.
31. Remove the bolts (1) holding left transmission mount (2) to the transmission (3).
32. Remove the left transmission mount (2).
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
steve
Monday, May 23, 2011 1:26:07 PM Page 26 © 2006 Mitchell Repair Information Company, LLC.
