Chrysler 62TE - Exploded View of Valve Body

Fig. 599: Exploded View Of Valve Body
Courtesy of CHRYSLER LLC
1 - CONVERTER CLUTCH SWITCH VALVE 6 - MANUAL
VALVE
2 - L/R SWITCH VALVE 7 -
PRESSURE
REGULATOR
VALVE
3 - SOLENOID SWITCH VALVE
8 - TORQUE
CONVERTER
REGULATOR
VALVE
4 - DC SWITCH VALVE
9 -
CONVERTER
CLUTCH
CONTROL
VALVE
5 - LC SWITCH VALVE -
NOTE: Use exploded view above for disassembly.
