Chrysler 62TE - Direct Clutch Compressed

20. Remove the inner and outer spline frictions (2, 3).
Fig. 371: Direct Clutch Compressed
Courtesy of CHRYSLER LLC
21. Install Compressor 8250 (2) over the direct clutch balance piston (3) and place onto a press (1).
22. Compress sprin
g
to remove the snap rin
g
(4) at the direct clutch balance piston.
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
