Fig. 573: Impeller
Courtesy of CHRYSLER LLC
The impeller (3) is an integral part of the converter housing. The impeller consists of curved blades placed
radially along the inside of the housing on the transmission side of the converter. As the converter housing is
rotated by the engine (4,5), so is the impeller, because they are one and the same and are the driving member of
the system.
TURBINE
1 - ENGINE FLEXPLATE 4 - ENGINE ROTATION
2 - OIL FLOW FROM IMPELLER SECTION
INTO TURBINE SECTION
5 - ENGINE ROTATION
3 - IMPELLER VANES AND COVER ARE
INTEGRAL
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
