80. Remove the differential cover bolts (1).
Fig. 104: Differential Cover
Courtesy of CHRYSLER LLC
81. Remove the differential cover (1).
82. Remove the out seal (2), oil singer (3) and the small bearing cup (4).
83. Remove the large bearing cup.
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
