Chrysler 62TE - Spring Compressor 5059-A

58. Install spring compressor disk 6057 (1), spring compressor 5059-A (2) and forcing screw 5058A-3 (3).
Fig. 83: Spring Compressor 5059-A
Courtesy of CHRYSLER LLC
59. Compress low/reverse spring using spring compressor 5059-A (4).
1 - SPRING COMPRESSOR DISC 6057
2 - SPRING COMPRESSOR 5059-A
3 - FORCING SCREW 5058A-3
1 - LOW/REVERSE CLUTCH RETURN SPRING
2 - SNAP RING (INSTALL AS SHOWN IN
ILLUSTRATION)
3 - SPRING COMPRESSOR DISC 6057
4 - SPRING COMPRESSOR 5059-A
5 - FORCING SCREW 5058A-3
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
