Chrysler 62TE - Rear Sun Gear & #7 Needle Bearing; Front Carrier & Rear Annulus Assembly

Fig. 140: Rear Sun Gear & #7 Needle Bearing
Courtesy of CHRYSLER LLC
32. Install rear sun gear (2) and number seven needle bearing (1).
Fig. 141: Front Carrier & Rear Annulus Assembly
Courtesy of CHRYSLER LLC
33. Install front carrier/rear annulus assembl
y
(2) and number six needle bearin
g
(1).
1 - #7 NEEDLE BEARING
2 - REAR SUN GEAR
1 - #6 NEEDLE BEARING
2 - FRONT CARRIER AND REAR ANNULUS
ASSEMBLY (TWIST AND PULL OR PUSH TO REMOVE
OR INSTALL).
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
