Chrysler 62TE - Pinion Shaft; Pinion Gear & Washer

8. Remove side gear (1).
Fig. 424: Pinion Shaft
Courtesy of CHRYSLER LLC
9. Remove pinion shaft (1).
Fig. 425: Pinion Gear & Washer
Courtesy of CHRYSLER LLC
1 - PINION SHAFT
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
