Chrysler 62TE - Input Clutch Assembly; No. 4 Thrust Plate

27. Remove number one needle bearing (1).
Fig. 58: Input Clutch Assembly
Courtesy of CHRYSLER LLC
28. Remove input clutch assembly (1).
Fig. 59: No. 4 Thrust Plate
Courtesy of CHRYSLER LLC
1 - #1 CAGED NEEDLE BEARING
2 - NOTE: TANGED SIDE OUT
1 - INPUT CLUTCH ASSEMBLY
2 - #4 THRUST WASHER
1 - OVERDRIVE SHAFT ASSEMBLY
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
