Chrysler 62TE - Transfer Plate; Bolts at Transfer Plate

Fig. 604: Transfer Plate
Courtesy of CHRYSLER LLC
5. Install the transfer plate (1).
Fig. 605: Bolts At Transfer Plate
Courtesy of CHRYSLER LLC
6. Install the bolts (1) at the transfer plate (2) and ti
g
hten to 6 N.m (50 in. lbs.).
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
