TORQUE CONVERTER LEAKAGE
Fig. 13: Converter Leak Points - Typical
Courtesy of CHRYSLER LLC
Possible sources of torque converter leakage are:
 Torque converter weld leaks at the outside diameter weld (1).
 Torque converter hub weld (2).
CLUTCH AIR PRESSURE TESTS
1 - OUTSIDE DIAMETER WELD
2 - TORQUE CONVERTER HUB WELD
3 - STARTER RING GEAR
4 - LUG
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
