Chrysler 62TE - Air Pressure Test Plate 9741

Fig. 14: Air Pressure Test Plate 9741
Courtesy of CHRYSLER LLC
Inoperative clutches can be located using a series of tests by substituting air pressure for fluid pressure using Air
Pressure Test Plate 9741.
1 - OVERDRIVE CLUTCH 5 -
LOW/REVERSE
CLUTCH
2 - REVERSE CLUTCH 6 - LOW
CLUTCH
3 - UNDERDRIVE CLUTCH
7 - DIRECT
CLUTCH
4 -2/4 CLUTCH
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
