Chrysler 62TE - Tapered Snap Ring

36. Remove 2/4 clutch pack (1, 2). Tag 2/4 clutch pack for reassembly identification.
Fig. 67: Tapered Snap Ring
Courtesy of CHRYSLER LLC
37. Remove tapered snap ring (3).
1 - CLUTCH PLATE (4)
2 - CLUTCH DISC (4)
1 - LOW/REVERSE CLUTCH REACTION PLATE
2 - SCREWDRIVER
3 - LOW/REVERSE TAPERED SNAP RING (TAPERED
SIDE UP)
4 - OIL PAN FACE
5 - LONG TAB
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
