Chrysler 62TE - Select Thinnest No. 4 Thrust Plate

Fig. 142: Front Sun Gear Assembly
Courtesy of CHRYSLER LLC
34. Install front sun gear assembly (1) and number four thrust washer (2).
Fig. 143: Select Thinnest No. 4 Thrust Plate
Courtesy of CHRYSLER LLC
35. Select the thinnest number four thrust plate thickness (2) and install to input clutch assembly. Use
petrolatum to retain (3).
1 - FRONT SUN GEAR ASSEMBLY
2 - #4 THRUST WASHER (FOUR TABS)
1 - OVERDRIVE SHAFT ASSEMBLY
2 - #4 THRUST PLATE (SELECT)
3 - 3 DABS OF PETROLATUM FOR RETENTION
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
