Chrysler 62TE - Output Nut Retaining Strap; Holder 9739

Fig. 74: Output Nut Retaining Strap
Courtesy of CHRYSLER LLC
45. Bend back the locking tabs (2) at the output transfer gear retaining strap (3).
46. Remove the bolts (1) at the output transfer gear retaining strap (3).
47. Remove the output transfer gear retaining strap (3).
Fig. 75: Holder 9739
Courtesy of CHRYSLER LLC
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
