Chrysler 62TE - Compounder Transfer Gear Bearing; Rear Carrier

54. Using Bearing Puller 5048 with Jaws 5048-5 and Thrust Pad L-4539-2 (1) remove output gear bearing
cone.
Fig. 79: Compounder Transfer Gear Bearing
Courtesy of CHRYSLER LLC
55. Using Press Puller C-293-PA (1), Adaptors 9738 (3) and Press Plug 9678 remove compounder transfer
gear bearing cone.
Fig. 80: Rear Carrier
