Chrysler 62TE - Input Hub Tapered Snap Ring; Tap on Input Hub

Fig. 312: Input Hub Tapered Snap Ring
Courtesy of CHRYSLER LLC
16. Remove input hub tapered snap ring (2).
Fig. 313: Tap On Input Hub
Courtesy of CHRYSLER LLC
17. Tap on input hub with soft faced hammer (2) and separate input hub from OD/Reverse piston and clutch
1 - INPUT SHAFT
2 - INPUT HUB SNAP RING (TAPERED SIDE UP WITH
TABS IN CAVITY)
3 - SNAP RING PLIERS
1 - INPUT SHAFT AND HUB ASSEMBLY
2 - SOFT FACED HAMMER
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
