Chrysler 62TE - Pinion Gear and Washer

Fig. 432: Pinion Gear And Washer
Courtesy of CHRYSLER LLC
3. Install both pinion gears (1) and washers (2) to case, while orientating washer tabs to notch in case.
Fig. 433: Pinion Shaft
Courtesy of CHRYSLER LLC
1 - PINION GEAR
2 - TABBED WASHER
3 - LOCATING TAB
4 - NOTCH
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
