Chrysler 62TE - Differential Assembly Installation

Fi
g
. 430: Thrust Washer
Courtesy of CHRYSLER LLC
1. Install side gear thrust washer (1) to differential case.
Fig. 431: Differential Side Gear
Courtesy of CHRYSLER LLC
2. Install side
g
ear (1) to differential case.
1 - THRUST WASHER
NOTE: The differential is serviced as an assembly. Differential service is limited to
bearing cups and cones. Any other differential component failure must be
remedied by differential assembly and transfer shaft replacement.
1 - DIFFERENTIAL SIDE GEAR
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
