Chrysler 62TE - Large Side Pinion Bearing

Fig. 440: Ring Gear Side Bearing
Courtesy of CHRYSLER LLC
12. Using Installer C-4213 (2) and a press (1), install differential bearing (3) to ring gear side of the
differential.
Fig. 441: Large Side Pinion Bearing
Courtesy of CHRYSLER LLC
13. Using Installer MD998911 (1) and a press, install the large pinion bearing to the pinion shaft.
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
