. 362: Solenoid Pack Electrical Connect

Courtesy of CHRYSLER LLC

3. Connect the electrical connectors (1, 2) to the pressure control solenoid and line pressure sensors.

4. Install valve body. See Transmission and Transfer Case/Automatic - 62TE/VALVE BODY -

Installation

ASSEMBLY, UNDERDRIVE COMPOUNDER

DESCRIPTION

The underdrive compounder assembly replaces the 41TE transfer shaft. The transaxle case is modified to

accommodate the additional components. The main components of the underdrive compounder assembly are

the low clutch (LC), direct clutch (DC), overrunning clutch (ORC), simple planetary gear set and bearing

retainer transfer/underdrive shaft.

DISASSEMBLY

Fig. 363: Planetary Gear Set - Output Hub

Courtesy of CHRYSLER LLC

1. Remove the planetar

ear set/output hub (1).

2009 Chrysler Town & Country LX

2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
