5. Separate differential cover (1) from case (2) using suitable screwdrivers at position.
Fig. 421: Differential Support
Courtesy of CHRYSLER LLC
6. Lift support (1) from case (2).
1 - DIFFERENTIAL SUPPORT
2 - DIFFERENTIAL CASE
3 - SCREWDRIVER
4 - RELIEF (2 @ 180° APART)
1 - DIFFERENTIAL SUPPORT
2 - DIFFERENTIAL CASE
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
