Chrysler 62TE - Snap Ring Underdrive Compounder; Bolts at Compounder

Fig. 92: Snap Ring Underdrive Compounder
Courtesy of CHRYSLER LLC
68. Remove the snap ring (1) at the underdrive compounder assembly (2).
Fig. 93: Bolts At Compounder
Courtesy of CHRYSLER LLC
69. Remove four bolts (1) at the compounder bearing retainer.
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
