Chrysler 62TE - 62 TE View through Input Speed Sensor Hole; Oil Pump O-Ring

Fig. 144: 62TE View Through Input Speed Sensor Hole
Courtesy of CHRYSLER LLC
36. Install input clutch assembly into position and verify that it is completely seated by viewing through input
speed sensor hole (3). If view through input speed sensor hole is not as shown in illustration, the input
clutch assembly (2) is not seated properly.
Fig. 145: Oil Pump O-Ring
Courtesy of CHRYSLER LLC
37. Remove oil pump O-rin
g
(2). Be sure to reinstall oil pump O-ring after selecting the proper number
1 - OIL PUMP ASSEMBLY
2 - O-RING
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
