Chrysler 62TE - Differential out and in; Set Screw at Park Pawl Shaft

Fi
g
. 105: Differential Out And In
Courtesy of CHRYSLER LLC
84. Remove the differential.
85. Remove the manual lever and TRS. See Transmission and Transfer Case/Automatic -
62TE/SENSOR, Transmission Range
- Removal.
Fig. 106: Set Screw At Park Pawl Shaft
Courtesy of CHRYSLER LLC
86. Remove the set screw (1) for the park pawl shaft.
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
steve
Monday, May 23, 2011 1:26:07 PM Page 69 © 2006 Mitchell Repair Information Company, LLC.
