19. Refer to the illustration as necessary when performing the following steps.
Fig. 338: Seating Tapered Snap
Courtesy of CHRYSLER LLC
20. Seat tapered snap ring (1) to ensure proper installation.
6 - INPUT CLUTCH ASSEMBLY
1 - OVERDRIVE/UNDERDRIVE CLUTCHES REACTION
PLATE TAPERED SNAP RING
2 - SCREWDRIVER
NOTE: Do not reuse tapered snap ring.
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
steve
Monday, May 23, 2011 1:26:09 PM Page 197 © 2006 Mitchell Repair Information Company, LLC.
