Fig. 598: Tapered Bore And Check Balls
Courtesy of CHRYSLER LLC
11. Remove the check balls (2) if equipped.
NOTE: The valve body contains some check balls that are pressed into a tapered
bore (1). These check balls are not removable
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
steve
Monday, May 23, 2011 1:26:13 PM Page 372 © 2006 Mitchell Repair Information Company, LLC.
