Chrysler 62TE - Page 348

Fig. 569: Ignition Key/Switch Positions
Courtesy of CHRYSLER LLC
The Brake Transmission Shifter/Ignition Interlock (BTSI) is engaged whenever the ignition switch is in the
LOCK or ACC position. An additional electrically activated feature will prevent shifting out of the PARK
p
osition unless the brake pedal is depressed at least one-half inch. When the key is in the ON position and the
b
rake pedal is depressed, the shifter is unlocked and will move into any position.
1 - LOCK
2 - ACC
3 - ON
4 - START
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
