3. Place OD/Reverse piston (1) return spring (2) and snap ring (3) into position.
Fig. 322: Snap Ring
Courtesy of CHRYSLER LLC
4. Using an arbor press (1) and Disk 6057 (4), install OD/Reverse piston (5), return spring (6) and snap ring
(3).
3 - SNAP RING
4 - O-RING
1 - ARBOR PRESS RAM (COMPRESS RETURN SPRING
JUST ENOUGH TO REMOVE OR INSTALL SNAP RING)
2 - SCREWDRIVER
3 - SNAP RING
4 - Disk 6057
5 - OD/REVERSE PISTON
6 - RETURN SPRING
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
