Fig. 203: Rear Mount & Bolts
Courtesy of CHRYSLER LLC
16. Install the rear mount and bolts, tighten to 100 N.m (74 ft. lbs.).
Fig. 204: Front Mount Bracket Bolts
Courtesy of CHRYSLER LLC
17. Install the starter motor along with the front mount bracket.
18. Install the front mount bracket bolts (1) and tighten to 100 N.m (74 ft. lbs.).
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
