Fig. 212: Crankshaft Position Sensor
Courtesy of CHRYSLER LLC
30. Install and connect crankshaft position sensor (1) and tighten to 12 N.m (105 in. lbs.).
Fig. 213: Cooler Lines At Transaxle
Courtesy of CHRYSLER LLC
31. Connect oil cooler lines to transaxle. An audible 'click' should be heard. Verif
y
connection b
y
pullin
g
