. 465: Ground Cable
Courtesy of CHRYSLER LLC
15. Remove the bolt (2) at the ground cable (3).
16. Remove the clip (1) at the valve body pan.
17. Move cable away from the valve body pan.
Fig. 466: Pressure Tap Plug
Courtesy of CHRYSLER LLC
18. Remove the pressure tap plug (2) at valve body oil pan.
19. Remove the lower valve body oil pan bolts (1) and drain transmission fluid.
20. Remove the valve bod
oil pan.
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
