Chrysler 62TE - Page 291

Fig. 474: Wheel Opening Splash Shield
Courtesy of CHRYSLER LLC
13. Move left side inner wheel splash shield (2) into place.
14. Install the left side inner wheel splash shield screws (1).
15. Lower the vehicle.
Fig. 475: Power Steering Lines
Courtesy of CHRYSLER LLC
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
