Fig. 479: Speed Sensors
Courtesy of CHRYSLER LLC
The Output Speed Sensor (2) is a two-wire magnetic pickup device that generates AC signals as rotation occurs.
Fig. 480: Speed Sensor O
-Ring
Courtesy of CHRYSLER LLC
The Output Speed Sensor (1) is bolted to the transaxle case and uses a O-rin
g
(2) to seal it to the transaxle case.
