Fig. 482: Speed Sensors
Courtesy of CHRYSLER LLC
1. Unplug the electrical connector at the output speed sensor (2).
Fig. 483: Speed Sensor O
-Ring
Courtesy of CHRYSLER LLC
2. Remove the bolt at output speed sensor (1).
3. Pull up on output speed sensor to remove.
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
