Fig. 487: Speed Sensors
Courtesy of CHRYSLER LLC
The Input Speed Sensor (1) is a two-wire magnetic pickup device that generates AC signals as rotation occurs.
Fig. 488: Speed Sensor O
-Ring
Courtesy of CHRYSLER LLC
NOTE: Always use a new O-ring
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
