Chrysler 62TE - Page 301

Fig. 490: Speed Sensors
Courtesy of CHRYSLER LLC
1. Unplug the electrical connector at the input speed sensor (1).
Fig. 491: Speed Sensor O
-Ring
Courtesy of CHRYSLER LLC
2. Remove the bolt at input speed sensor.
3. Pull up on input speed sensor (1) to remove.
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
