Chrysler 62TE - Page 314

Fig. 512: Roll Pin At Manual Lever
Courtesy of CHRYSLER LLC
4. Install the roll pin (3) to the TRS/rooster comb (1) using a pin punch (2).
Fig. 513: Manual Lever Set Screw
Courtesy of CHRYSLER LLC
5. Install the set screw (1) at manual lever (2) and ti
g
hten to 1 N.m (10 in. lbs.).
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
