3. Install the WIN (2) and install the mounting screws (1).
Fig. 534: WIN & Shifter Electrical Connectors
Courtesy of CHRYSLER LLC
4. Connect the electrical connectors (3, 4) at the WIN (1) and the shifter (2).
Fig. 535: Center Stack Lower Cover
Courtesy of CHRYSLER LLC
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
steve
Monday, May 23, 2011 1:26:12 PM Page 327 © 2006 Mitchell Repair Information Company, LLC.
