13. Raise the vehicle on a hoist.
14. Remove the front left side inner wheel splash screws from front side of wheel opening (1) and fold shield
(2) back.
15. Turn the wheel (3) fully to the left.
Fig. 554: Ground Cable
Courtesy of CHRYSLER LLC
16. Remove the bolt (2) at the ground cable (3).
17. Remove the clip (1) at the valve body pan.
18. Move cable awa
y
from the valve bod
y
pan.
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
