10. Install the bolt at the ground cable and tighten to 10 N.m (90 in. lbs.).
11. Install the clip to the valve body oil pan.
Fig. 562: Fasteners & Front Sound Dampener Cover
Courtesy of CHRYSLER LLC
12. Install the Front Sound Dampener Cover (2) and fasteners (1).
Fig. 563: Wheel Opening Splash Shield
Courtesy of CHRYSLER LLC
13. Move left side inner wheel splash shield (2) into place.
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
steve
Monday, May 23, 2011 1:26:12 PM Page 343 © 2006 Mitchell Repair Information Company, LLC.
