Fig. 594: Bolts At Transfer Plate
Courtesy of CHRYSLER LLC
7. Remove the bolts (1) at the clamping plate (2).
Fig. 595: Transfer Plate
Courtesy of CHRYSLER LLC
8. Remove the clampin
g
plate (1).
