42. Install input clutch assembly (1).
Fig. 147: Caged Needle Bearing
Courtesy of CHRYSLER LLC
43. Install number one caged needle bearing (1) note: tanged side out (2).
3836240AB 2.39 mm (0.094 in.)
4431669AB 2.46 mm (0.097 in.)
3836241AB 2.62 mm (0.103 in.)
4446670AB 2.67 mm (0.105 in.)
4446671AB 2.90 mm (0.114 in.)
1 - #1 CAGED NEEDLE BEARING
2 - NOTE: TANGED SIDE OUT
CAUTION: The cooler bypass valve must be replaced if transaxle failure has
occurred. Do not attempt to reuse or clean old valve.
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
