Chrysler 62TE - Page 97

Fig. 150: Front Pump 62TE
Courtesy of CHRYSLER LLC
46. Install oil pump (2).
47. Install oil pump-to-case bolts (1) and tighten 30 N.m (265 in. lbs.).
Fig. 151: Output Gear Stirrup
Courtesy of CHRYSLER LLC
48. Install output
g
ear stirrup (1) with serrated side out.
1 - STIRRUP
2 - OUTPUT GEAR RETAINING BOLT
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
