Option Name Description
[3] Coast and reset inverse Reset and coast stop inverted input (NC).
Leave motor in free mode and reset the
drive.
Logic 0=>coast stop.
Logic 1 to Logic 0=>reset.
[4] Quick stop inverse Inverted input (NC). Generate a stop in
accordance with the quick stop ramp time
set in parameter 3-81 Quick Stop Ramp
Time. When the motor stops, the shaft is
in free mode.
Logic 0=>quick stop.
[5] DC brake inverse Inverted input for DC brake (NC). Stop the
motor by energizing it with a DC current
for a certain time period. See parameter
2-01 DC Brake Current to parameter 2-04
DC Brake Cut In Speed [Hz]. The function is
only active when the value in parameter
2-02 DC Braking Time is different from 0.
Logic 0=>DC brake.
[6] Stop inverse Stop inverted function. Generate a stop
function when the selected terminal
goes from logic 1 to logic 0. The stop is
performed according to the selected ramp
time (parameter 3-42 Ramp 1 Ramp Down
Time, parameter 3-52 Ramp 2 Ramp Down
Time, parameter 3-62 Ramp 3 Ramp down
Time, parameter 3-72 Ramp 4 Ramp Down
Time).
NOTICE
When the drive is at the torque
limit and has received a stop
command, it may not stop by itself.
To ensure that the drive stops,
configure a digital output to [27]
Torque limit & stop and connect
this digital output to a digital input
that is configured as coast.
[8] Start Select start for a start/stop command.
Logic 1 = start, logic 0 = stop.
[9] Latched start The motor starts when a pulse is applied
for minimum 4 ms. The motor stops when
stop commands are given.
112 | Danfoss A/S © 2024.01 AU275649936274en-001401 / 130R0507
Programming Guide | VLT® AutomationDrive FC 360
