Table 15: Preset Ref. Bit
Preset ref. bit 2 1 0
Preset ref. 0 0 0 0
Preset ref. 1 0 0 1
Preset ref. 2 0 1 0
Preset ref. 3 0 1 1
Preset ref. 4 1 0 0
Preset ref. 5 1 0 1
Preset ref. 6 1 1 0
Preset ref. 7 1 1 1
Table 16: Shut Down/Catch Up
Shut down Catch up
Unchanged speed 0 0
Reduced by %-value 1 0
Increased by %-value 0 1
Reduced by %-value 1 1
Table 17: Preset Ramp Bits
Preset ramp bit 1 0
Ramp 1 0 0
Ramp 2 0 1
Ramp 3 1 0
Ramp 4 1 1
5-11 Terminal 19 Digital Input
Default value: [10] Reversing Parameter type: Option
Setup: All setups Conversion index: –
Data type: Uint8 Change during operation: True
Select the function from the available digital input range.
For the options of parameter 5-11 Terminal 19 Digital Input, see parameter 5-10 Terminal 18 Digital Input.
5-12 Terminal 27 Digital Input
Default value: [2] Coast inverse Parameter type: Option
Setup: All setups Conversion index: –
Danfoss A/S © 2024.01 AU275649936274en-001401 / 130R0507 | 117
