Programming Guide | VLT® AutomationDrive FC 360
Option Name Description
[45] Bus ctrl. Control the digital output/relay via
fieldbus. The state of the output is set
in parameter 5-90 Digital & Relay Bus
Control. The output state is retained in the
event of fieldbus timeout.
[46] Bus control, timeout: On Control output via fieldbus. The state of
the output is set in parameter 5-90 Digital
& Relay Bus Control. When bus timeout
occurs, the output state is set high (On).
[47] Bus control, timeout: Off Control output via bus. The state of the
output is set in parameter 5-90 Digital &
Relay Bus Control. When a bus timeout
occurs, the output state is set low (off).
[56] Heat sink cleaning warning, high
[60] Comparator 0 See parameter group 13-1* Comparators.
If comparator 0 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
[61] Comparator 1 See parameter group 13-1* Comparators.
If comparator 1 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
[62] Comparator 2 See parameter group 13-1* Comparators.
If comparator 2 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
[63] Comparator 3 See parameter group 13-1* Comparators.
If comparator 3 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
[64] Comparator 4 See parameter group 13-1* Comparators.
If comparator 4 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
[65] Comparator 5 See parameter group 13-1* Comparators.
If comparator 5 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
[70] Logic rule 0 See parameter group 13-4* Logic Rules.
If logic rule 0 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
[71] Logic rule 1 See parameter group 13-4* Logic Rules.
If logic rule 1 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
[72] Logic rule 2 See parameter group 13-4* Logic Rules.
If logic rule 2 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
Danfoss A/S © 2024.01 AU275649936274en-001401 / 130R0507 | 133
