Programming Guide | VLT® AutomationDrive FC 360
Option Name
[0] 0-20 mA
[1] 4-20 mA
[2] Digital Output
6-71 Terminal 45 Analog Output
Default value: [0] No operation Parameter type: Option
Setup: All setups Conversion index: –
Data type: Uint8 Change during operation: True
Select the function of Terminal 45 as an analog current output.
Option Name Range
[0] No operation
[100] Output frequency 0–100 Hz
[101] Reference Min
Ref
–Max
Ref
[102] Process Feedback Min
FB
–Max
FB
[103] Motor Current 0–I
max
[104] Torque rel to limit
[105] Torq relate to rated
[106] Power 0–P
nom
[107] Speed
[111] Speed Feedback
[113] PID Clamped Output
[139] Bus Control 0–100%
[143] Ext. CL 1
[254] DC Link Voltage
6-72 Terminal 45 Digital Output
Default value: [0] No operation Parameter type: Option
Setup: All setups Conversion index: –
Data type: Uint8 Change during operation: True
Select the function of terminal 45 as a digital current output. See also parameter 6-70 Terminal 45 Mode.
Danfoss A/S © 2024.01 AU275649936274en-001401 / 130R0507 | 149
