Option Name
[1693] Warning Word 2
[1694] Ext. Status Word
[1695] Ext. Status Word 2
[1697] Alarm Word 3
[1837] Temp. Input X48/4
[1838] Temp. Input X48/7
[1839] Temp. Input X48/10
[1855] Active Alarm Number
[1856] Active Warning Number
[1866] Switching Frequency
[1888] Motor current
[3421] PCD 1 Read For Application
[3422] PCD 2 Read For Application
[3423] PCD 3 Read For Application
[3424] PCD 4 Read For Application
[3425] PCD 5 Read For Application
[3426] PCD 6 Read For Application
[3427] PCD 7 Read For Application
[3428] PCD 8 Read For Application
[3429] PCD 9 Read For Application
[3430] PCD 10 Read For Application
[3450] Actual Position
[3456] Track Error
9-18 Node Address
Default value: 126 Parameter type: Range (1–126)
Setup: 1 setup Conversion index: 0
Data type: Uint8 Change during operation: True
Enter the station address in this parameter or, alternatively, in the hardware switch. To adjust the station address in parameter 9-18 Node
Address, set the hardware switch to 126 or 127 (that is all switches set to on). Otherwise, this parameter shows the actual setting of the
switch.
9-19 Drive Unit System Number
Default value: 1037 Parameter type: Range (0–65535)
