Option Name Description
[4] Positive SW Limit Exceeded Check if the value in parameter 34-50
Actual Position exceeds the value in
parameter 33-42 Positive Software Limit,
move in the opposite position.
[5] Negative SW Limit Exceeded Check if the value in parameter 34-50
Actual Position exceeds the value in
parameter 33-41 Negative Software Limit,
move in the opposite position.
[7] Brake Wear Limit Exceeded If the motor is stopped and the brake is
closed, but the value in parameter 34-50
Actual Positionhas a move exceeded the
value in parameter 37-11 Pos. Brake Wear
Limit, check the mechanical brake.
[8] Quick Stop Set by command from DI or bus.
[9] Tracking Error Limit Exceeded Command position and parameter 34-50
Actual Position difference is greater than
parameter 32-67 Max. Tolerated Position
Error. Increase the value of parameter
32-67 Max. Tolerated Position Error
or check the settings about position
feedback.
[12] Reverse Operation Check if parameter 37-15 Pos. Direction
Block has been set to [1] Block Reverse,
move in the opposite position or set
parameter 37-15 Pos. Direction Block to
[0] No Blocking.
[13] Forward Operation Check if parameter 37-15 Pos. Direction
Block has been set to [2] Block Forward,
move in the opposite position or set
parameter 37-15 Pos. Direction Block to
[0] No Blocking.
[20] Home Position Not Found The home position is not found.
[25] Tuning Timeout After the speed ramping down, the
position is turned into the target window.
In this state, if the time set in parameter
37-09 Pos. Max Tuning Time is exceeded,
ALARM 120, Position Control Fault is
reported and the reason shown here is
[25] Tuning Timeout.
37-19 Pos. New Index
Default value: 0 Parameter type: Range (0–255)
Setup: 1 setup Conversion index: 0
Data type: Uint8 Change during operation: True
302 | Danfoss A/S © 2024.01 AU275649936274en-001401 / 130R0507
Programming Guide | VLT® AutomationDrive FC 360
